Heated Floor Touch Screen Thermostat Weekly Programmable Thermostat
Weekly circulation digital programming Touch Screen Thermostat with LCD screen, which has 6-event everyday. Manual mode and
programme mode could be selected. The thermostat is recommended for
control of electric heating devices or on/off valve actuator used
in hydronic floor heating.
The SK81 series Touch Screen Thermostat has been developed to
control electric underfloor . These units are designed for use in
commercial, industrial, civil and domestic properties.
Now you don't need to choose between saving money or staying
comfortable. The thermostat can help you save up energy costs every
year when you use a pre-set heating program schedule. When you use
our intuitive mobile app, you can adjust your room thermostat
schedule around your life, so you're not needlessly heating an
empty home.Items included: (1) Thermostat, (1) Thermostat Floor
Sensor, (2) Mounting Screws, (1) Manual,
Application
For the control of warm-water(floor) heating systems and direct
electric heatings systems used in Commercial buildings, Residential
buildings, Light industrial buildings.
Programming
| Choice of 7 day, 5/2 day programmable; |
| non-programmable (installer selectable); |
| 6 time and 4 temperature settings every day; |
| pre-programmed or personalized schedule; |
| Energy saving up to 33%; |
Display
| Large, touchscreen display; |
| European standard installation box; |
| White lighted display for easier low-light viewing; |
| Comfort & Convenience; |
| Intuitive menu-driven set-up, programming and operation; |
| Permanent program retention during power loss; |
| Setpoint temperature limited range capable; |
| Enhanced touchscreen security prevents tampering; |
| Can switch upto 16 amps (230v); |
| Temperature display resolution: 0.5 C; |
A / AF/ F models all in one
Combination of 3 models;
A - Air only, with built-in sensor;
F - Floor only,controls floor temperature;
AF - Controls air temperature with ability to limit the
floor temperature
Each thermostat is equipped with built-in sensor and a 3 meter
floor sensor.
Specifications
| Power supply: | 230VAC (120VAC optional) |
| Inputs: | 2 x NTC10K temperature sensors |
| Output: | 1 x switch relay(R1),max 3500watts |
| Operating RH: | 0~95% (non condensing) |
| Dimensions: | 121mm x 80mm x18mm |
| Backlight life: | 5,000 hours |
Useful settings
Vacation mode(frost protection mode)
Switching differential setting
Floor temperature limit
Packing details
1pc/inner box, 50pcs/carton
Carton size: 51x22x36cm
FAQ
Are you manufacturer?
Answer: Yes,we are manufacturer in thermostats,we have R&D
department.Factory locate in Nanjing,China.
What is your quality warranty?
Answer: All of our products are with 2 year quality warranty.
Should we use our logo/brand?
Answer: Yes, of course. OEM available,both on package or devices.
How can I get a sample? What’s the sample fee? How long will it
take?
Answer: All sample available with sample fee,sample fee is
confirmed with exact model you choose.Samples can be ready 3-4
workdays.
What about your after-sale services?
Answer: We have 100% QC before shipment. If there are some
unexpected problems happen, we hope to solve these problems with
our customers through friendly ways as below:
1, If it’s quality problem, customers must provide photos or videos
and other evidences to us for identify. After confirmation, we’ll
send the new products to replace the damages in next order.
2, If it’s man-made damaged, customers should take full
responsibility.
