    Networking Function Touch Screen Heating Thermostat 50/60HZ Frequency

    Ask Lasest Price
    Brand Name : Saiko
    Model Number : SK90
    Certification : CE
    Price : Negotiation
    Payment Terms : T/T, Western Union
    Supply Ability : 3000pcs/week
    Delivery Time : 3-15 work days
    • Product Details
    • Company Profile

    Networking Function Touch Screen Heating Thermostat 50/60HZ Frequency

    Networking Function Touch Screen Weekly Programmable Heating Thermostat


    SK90 Touch Screen Period Programming Thermostat Weekly circulation, it is possible to set 6 periods called events each day with corresponding pre-set temperatures, also you can select "period control mode" or "manual mode" according to your individual requirements. The thermostat is recommended for the control of electric heating devices or on/off valve actuator used in water-based heating systems.


    The SK90 is used for 2-position control with on/off output for the control the temperature by means of an NTC sensor placed externally or internally in the thermostat.
    The thermostat acquires the actual temperature with its built-in sensor or floor sensor, and the heating contact will close when the room temperature falls below the selected setpoint.


    Technical data


    Power SupplyAC200-240VAC 50/60HZ
    Accuracy±0.5ºC
    Probe sensorNTC
    Probe sensor<0.3W
    Load current3A(water heating),16A(electric heating)
    Temperature Adjustable Range5°C~90°C( can adjust to 35°C~90°C)
    Limit Temperature Range5°C~60°C( factory setting: 35°C)
    OutputSwitch relay
    Insulating conditionNormal environment
    Running programSet per 1 week as a cycle
    InstallationWall mounted
    Application

    Water Floor Heating System

    Electric Floor Heating System

    Infrared Heater System

    CertificateCE

    Networking Function Touch Screen Heating Thermostat 50/60HZ Frequency

    Networking Function Touch Screen Heating Thermostat 50/60HZ Frequency
    FAQ
    Q1Are you manufactory?
    A1Yes, we are professional manufacturer for thermostat and valves.
    Q2Can you pack this product with our color card and our brand
    logo?
    A2Customized color card is welcome with design in PDF,AI,CDR form.
    Q3We are one big company, and want to design our special package for this product, is it ok?
    A3Sure. Another customized package is welcome with design as gift box, display box and so on.
    Q4What is MOQ for this product in your company?
    A4MOQ is 1 pcs.

    Package
